APPLICATION
For use indoors, in cable ducts, outdoors and in ground
for power plants, industrial plants, as well as in local power
networks, if increased electrical protection is required.

CHARACTERISTICS
Voltage Rating Uo/U
0.6/1kV
Temperature Rating
Fixed: -20°C to +70°C
Flexed: -5°C to +70°C
Laboratory
Minimum Bending Radius
15 x overall diameter

CONSTRUCTION
Conductor
RE: Class 1 solid copper conductor
Insulation
PVC (Polyvinyl Chloride)
Binding Tape
PVC (Polyvinyl Chloride)
Concentric Conductor
Copper wires and copper tape
Sheath
PVC (Polyvinyl Chloride)
