The connecting cable between the frequency converter and the motor is suitable for fixed installation indoors or outdoors in dry or humid environments, such as paper industry, chemical industry, heavy industry, installation engineering, industrial automation, electromechanical complete equipment, machine tools, logistics transmission systems, production lines, etc.

Conductor material: multi strand bundle twisted fine copper wire conductor

Core wire insulation: special PE mixture insulation

Core wire identification: optional

Shielding: aluminum foil wrapping+tinned copper wire weaving

Sheath: Special PVC composite sheath

Sheath identification: optional (black)

Rated voltage: 600/1000V

Test voltage: 3500V

Flame retardant rating: compliant with IEC 60332-3;

Minimum bending radius: Fixed installation 4XD (cable outer diameter) occasionally moved 15XD (cable outer diameter)

Working temperature: Fixed installation -30 ℃~+70 ℃ Occasionally moving -15~+70 ℃
