Applications

These heavy duty cables are designed for applications such as longwall shearers, continuous miners, loaders, drills, conveyors, pumps and mobile equipment where grounding conductors, a ground check conductor and metallic shielding are required.

Standards

• ICEA S-75-381/NEMA WC 58

• ASTM B 172

• ASTM B 33

• CAN/CSA-C22.2 No.96

Construction

• Conductors: Stranded annealed tinned copper conductor.

• Insulation:EPR.

• Insulation Shield:Tinned copper/textile braid.

• Ground Check Conductor:Tinned copper conductor with a yellow polypropylene insulation.

• Grounding Conductor:Tinned copper conductor.

• Sheath: Reinforced extra-heavy-duty Chlorinated Polyethylene(CPE), black. Other sheath materials can be offered upon request.

Options:

Other jacket materials such as CSP/PCP/NBR/PVC are available upon request.

Two-layer jacket with reinforcing fibre between the two layers can be offered as an option.

Mechanical and Thermal Properties

• Minimum Bending Radius: 6×OD

• Maximum Operating Temperature: +90º
