Double Sheath High Flexibility Shielded Data Cable manufacturer, focusing on the field of high flexibility cable, factory direct sale, quality assurance.
Double Sheathed Highly Flexible Shielded Data Cables are used where frequent continuous repetitive movements are required, and are also suitable for situations where there is free movement with moderate mechanical stress.
The shielded cables are braided shielded and the high density of the shield ensures interference-free transmission of signals and impulses.
The double-sheathed cables are lined with an inner layer that enhances the mechanical stress resistance of the cables and is also suitable for flexible fixed installations under moderate mechanical stress, etc.
Double-sheathed, highly flexible data transmission cables are used in drag chains and moving machine parts, and are even more effective when used in conjunction with drag chains.
Composition
Conductor: fine oxygen-free bare copper wire, multi-stranded flexible conductor, in accordance with GB/T3956 (VDE0295/IEC60228) 60228 Class5 or 6 standard.
Insulation: high-strength modified PVC or PE materials with excellent insulation and electrical properties, colour differentiation, no repetition (can be customized according to customer requirements)
Cable formation: short pitch stranded, 12 cores and above using composite cable structure.
Inner sheath: high strength special composite sheath material.
Shield: copper mesh braided shield, braiding density ≥ 85%
Outer sheath: high strength and low viscosity special PVC composite material;
Sheath colour: grey (default), black, orange, green (other colours can be customized according to customer requirements)
Technical parameters
Rated voltage: <0.5mm2, 300/300V; ≥0.5mm2, 300/500V
Test voltage: 0.14mm2: 1200V, >0.14mm2: 1500V
Insulation resistance ≥20MΩ/km (20°C)
Zui small bending radius: mobile use: 7.5X cable O.D., fixed installation: 4X cable O.D.
Temperature range: Mobile use: -5°C~70°C, Fixed installation: -20°C~80°C
Ask
Can ordinary cable RVVP be used in cable drag chains?
Answer
Strictly speaking, RVVP can't be used in cable drag chains. Ordinary cable RVVP is a flexible cable for fixed laying, although it can be used for occasional mobile use, but it is not suitable for frequent back and forth bending of the movement occasions.
Ask
What is the price of 5 million times drag chain cable?
Answer
The price of drag chain cable mainly depends on the raw material and process, the organic combination of the two determines the level of drag chain cable bending resistance. From the name, there is no way to judge the raw material used in 5 million times drag chain cable. The ‘every time’ in the number of times the drag chain cable bends represents a dynamic movement process in which the cable follows the drag chain to move back and forth, and the difficulty of this process also determines the raw materials and processes used in the 5 million times drag chain cable, and even the price of the drag chain cable.
