It is suitable for lifting, long travelling material conveying and processing equipment towing system, such as indoor conventional cranes, harbour cranes, coal yard tippers, metallurgical cranes and so on.

Product features
  Long service life and stable quality, imported rubber material is more wear-resistant and resistant to harsh environments, suitable for outdoor.
Product Advantage
  -Professional cable structure, symmetrical stranding levels and mesh tensile treatment, greatly improving product quality and service life.
  -10 million times of back and forth cycle test and strict German testing standards, so that all the factory cable bending resistance, weather resistance, tensile strength is further guaranteed.

Technical Parameters
  Voltage: 0.6/1kv
  Test voltage: 3500V/5min(AC)
Minimum bending radius
  Fixed laying: 5x cable O.D.
  Mobile installation: 10x cable O.D.
Temperature range
  Fixed laying temperature -40℃～90
  Mobile temperature -35℃～90
  Oil resistance: very good
  Chemical resistance: excellent resistance to acids, alkalis, solvents and various hydraulic fluids, etc.
  Weather resistance: UV resistance, sunlight aging performance is excellent, suitable for outdoor use.
  Flame retardant properties: in line with IEC60332-1

Cable structure
  1、Conductor in accordance with VDE02956 category
  2, insulation special EPR rubber compound, insulation core black, white digital identification number
  3、Nylon reinforced core
  4、Inner jacket special CR rubber compound
  5、Braided reinforcement layer
  6、Outer jacket special CR rubber compound
