1. Executive standard
It is manufactured acconding to MT818.12.

It is fit for ac rated voltage up to and including 0.6/1kv, coal power equipment can transmit electricity use.

2. Characteristics

1. The highest rated temperature of the cable conductor is 70°C, when short circuit(teh longest duration of no more than 5s), cable conductor does not exceed the highest temperature of 160ºC.

2. During the cable laying, the ambient temperature must be above 0 °C.

3. The minimum bending radius radius 15 times of cable diameter.
