Applications

For laying indoors, in tunnel or cable trench with large difference of level able to bear external mechanical forces.

Standards

International: IEC 60502-2, IEC 60228 IEC 60840;IEC62067

China: GB/T 12706.2-2008

Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage: 0.6/1kV,

Maximum Conductor Temperature: under normal (90°C), emergency (130°C) or short circuit no more than 5 s (250°C) conditions.

Min. Ambient Temp. 0°C, after installation and only when cable is in a fixed position

Min. Bending Radius: 20 x cable O.D for single-core non-armoured cables

                   15 x cable O.D for single-core armoured cables

                    15 x cable O.D for multi-core non-armoured cables

                   12 x cable O.D for multi-core armoured cables

Certificates

TUV, RoHS, CCC, ISO 9000,ISO10004 and more others at request

Marking

According to the customers' requirements

Nominal cross-sectional areas

1.5mm2, 2.5mm2, 4mm2, 6mm2, 10mm2, 16mm2, 25mm2, 35mm2, 50mm2, 70mm2, 95mm2, 120mm2, 150mm2, 185mm2, 240mm2, 300mm2.
