Use for hanging inside the elevator for the accompanying freely hanging length less than 80 meters, and the moving speed of no more than 4 m/s, also for reelingcableon lifter and travelling crane
Conductor: Meet GB 3956 Class 5 conductor standard
Insulation: PVC/D type PVC compound insulation
Color recognition: conform GB 5023.1 4.1 color identification for less than 5-core cable, Conform GB 5023.1 4.2 digit recognition for up to 5- core cable
• Core structure: core centered on bearing core (filler) twisted into line, after cabling, aluminum foil PP belt or non-woven fabric coated, etc.
• Sheath material: PVC/ST5 special PVC compound, black or gray (RAL7001)
• Application standards: GB/T 5023.6/IEC 60227-6,EN 50214-2006 enterprise standard

Technical parameters of Pvc Insulated Flat Cable
Rated voltage: Nominal conductor cross section 1mm2 or 1mm2 less cable: 300/500 v
Test voltage: rated voltage 300/500V, insulation thickness ≤ 0.6 mm: 1500 v,
Finished cable test voltage: 2000 v,
Rated voltage 450/750V, Insulation thickness > 0.6 mm:2500V,
Finished product test Voltage: 2500 v,
• minimum bending radius
Cable laying installation allowed bending radius should not less than 6 times of the cable's smaller side.
Static torsion Test: comply with the regulations of GB/T 5023.2 3.5
Temperature range,- 15 to + 70 ºC
