Technical performance
1.The conductor shall comply with the requirements of fifth kinds of soft round stranded conductors specified in GB/T 3956-2008
2.The highest operating temperature of Conductor: ethylene propylene rubber insulation 70ºC, 90ºC; silicone rubber insulation 90ºC.
3.The finished cable shall be to withstand the normal temperature torsion test and the low temperature torsion test specified in Appendix B of GB/T 29631-2013.
4.The finished cable shall be able to withstand weight test as specified in Appendix C of GB/T 29631-2013.
5.The finished cable shall be able to withstand the low temperature bending test specified in Appendix D of GB/T 29631-2013.
