Use characteristics and technical performance

1.The rated voltage U0/U 0.6/1kV

2.Cable conductor long-term working temperature :PVC insulated, nitrile PVC insuated, thermoplastic elastic body insulaton does not exceed 70ºC;Silicone rubber isnualtion does not exceed 180ºC

3.The minmum bending radius shoule not less than 6 times of cable diameter

4.Cable lowest runtime environment temperature:PVC insulated is not lower than 0ºC;Nitrile PVC composite insulation, thermoplastic projectile insulation not below -20ºC;Silicone rubber insulation not bellow to -40ºC

5.20ºC conducror DC resistance in accordance with the provisions of the GB/T 3956-2008.

6.Power frequency voltage test:3.5kV/5min cable breakdown.


Application

It is used as sighal transmission wire of applianles, meters and automatie control system in petroleum, chemisty power gmernting and metallurgy.
