Ⅰ Applications

This type of conductor can be used in dry and wet place,directly buried or outdoor. It also can used for power stations, industry.

Ⅱ Specification

Size:3×240(mm2)

Wire No/Dia:48/2.56(mm)

Conductor screen:0.7(mm)

Insulation thickness:2.5(mm)

Insulation screen:0.7(mm)

Copper tape screen:45*1*0.1(mm)

Inner sheath thickness:1.6(mm)

Steel wire Dia:3.15(mm)

Sheath thickness:3.3(mm)

Diameter:73.6(mm)

Voltage:12.5(A.C)

Max. D.C Resistance of Conductor:0.0754O /km
