APPLICATION

LSZH (Low Smoke Zero Halogen) electronic cables are used

for connection and signal transfer in measuring and control

equipment. For indoor installation in dry and wet rooms, for

installation under plaster.

CHARACTERISTICS

Voltage Rating

250/250V

Temperature Rating

Fixed: -40°C to +70°C

Flexed: +5°C to +70°C

Minimum Bending Radius

Fixed: 7.5 x overall diameter

CONSTRUCTION

Conductor

Generally to Class 5 fine-stranded copper conductor

Insulation

LSZH (Low Smoke Zero Halogen)

Sheath

LSZH (Low Smoke Zero Halogen)

Core Identification

Core 1: White

Core 2: Brown

Core 3: Green

Core 4: Yellow

Core 5: Grey

Core 6:

Pink

Core 7: Blue

Core 8:

Red

Core 9: Black

Core 10: Violet

Core 11: Grey/Pink

Core 12: Red/Blue

Core 13: White/Green

Outer Sheath Colour

Grey

STANDARDS

IEC/EN 60754-1/2, IEC/EN 61034-1/2

Flame Retardant according to IEC/EN 60332-1-2
