application

 is used as a data- and signal cable for power supply chains, sensor technology, computers and control devices for measurement and

control technology. It can be used in damp and wet areas but not outdoors. A long service life is achieved by the special

structure and PUR mixture of the cable.

construction

Superfine bare strands of copper wire, PVC core insulation, core coloursof the data cable acc. to DIN 47100. Cores twisted in

layers with very short lay lengths, PVC outer sheath, extensively resistant to oil and cooling liquid, flame retardant and

selfextinguishing (acc. DIN EN 60332-1-2 VDE 0482 part 332-1-2:2005-06). Colour grey (RAL 7001).

bending radius

 fixed installation:  5 x d

flexible application: 7,5 x d

temperature range

fixed installation: -40° C  /to +105° C  flexible application: VDE -30° C  /to +105° C

conductor cross-section（mm2）

0.14mm2~150mm2

approvals

VDE 0285, 0812
