APPLICATION

Power and auxiliary control cables for use in power networks,

underground, outdoor and indoor applications and for use in

cable ducting. For installation where fire, smoke emission and

toxic fumes create a potential threat to life and equipment.

CHARACTERISTICS

Voltage Rating Uo/U

1.9/3.3kV

Temperature Rating

Maximum Operating: +90ºC

Maximum Short-Circuit: +250°C

Minimum Bending Radius

15 x overall diameter

CONSTRUCTION

Conductor

Class 2 stranded copper

Insulation

XLPE (Cross-Linked Polyethylene)

Filler

HFFR (Halogen free flame retardant)

Armour

AWA (Aluminium Wire Armour)

Outer Sheath

HFFR (Halogen free flame retardant)

Core Identification

Brown

Sheath Colour

Black

STANDARDS

BS 6724, EN 60228

Low Smoke Zero Halogen to IEC/EN 61034, IEC/EN 60754

Flame retardant to IEC/EN 60332-1

UV Resistant
