System
This product is suitable for AC 50Hz, transmission of electrical energy in a power line whose voltage does not exceed 450/750V power.
Occasion
Power plants, fixed wiring, household appliances, meters, lighting and telecommunication equipment with AC voltage of 450/750V and below
Product characteristics
Insulation performance is good, have a certain acid and alkali resistance, oil resistance, moisture-proof characteristics; Stable structure, process of simple manufacturing, low price
Executive standard
GB/T 5023-2008 PVC insulated cable,wires and flexible wires with rated voltage of 450/750V and below

Rated voltage
0.45/0.75kV
Operating temperature
Cable conductor allows the highest working temperature 70 ºC for a long time.
Ambient temperature
The ambient temperature of the cable should not be lower than 0 ° C.
Laying temperature
The laying temperature of the cable should not be lower than 0ºC.
