Application:
The cable is used in fire extinguishing systems, sprinklers, control panels, and exit lights in high-rise buildings, hotels, hospitals, sub-ways, and public facilities

Construction:
1.    Conductor - Plain annealed class 2 stranded or class 5 flexible copper
2.    Fire Resistant layer - Mica Tape
3.    Insulation - Low smoke halogen-free (LSZH)

Cross Section:
Class 2 copper conductor: 2C1.0~2C2.5mm2
Class 5 copper conductor: 2C1.0~2C1.5mm2

Temperature characteristics:
Conductor operating temperature: -15ºC~90ºC
Min. temperatrue laying condition: 0ºC

Electrical Characteristics:
Rated voltage: 0.6/1 (1.2) kV
High voltage test: 3.5kV / 5min

Color:
Red, black or according to customer requirements
