Application
Wiring for electrical appliances, smaller size electric tools, instruments of various meters, and motorized lighting system.
Standards
IEC 60227,IEC 60228,IEC 60332,GB/T 5023,BS 6500,BS 6004,VDE 0281,0282 , EN 50525-1, AS/NZS 5000.2 etc.
Type and description |
No. | Type | Description |
1 | 60227 IEC 01 (BV) (H07V-U or H07V-R) | Single core solid or stranded conductor unsheathed cable
for general purposes |
2 | 60227 IEC 02 (RV) (H07V-K) | Single core flexible conductor unsheathed cable
for general purposes |
3 | 60227 IEC 05 (BV) (H05V-U or H05V-R) | Single core 70℃ solid or stranded conductor unsheathed cable
for internal wiring |
4 | 60227 IEC 06 (RV) (H05V-K) | Single core 70℃ flexible conductor unsheathed cable
for internal wiring |
5 | 60227 IEC 07 (BV-90) (H07V2-U or H07V2-R) | Single core 90℃ solid conductor unsheathed cable
for internal wiring |
6 | 60227 IEC 08 (RV-90) (H07V2-K) | Single core 90℃ flexible conductor unsheathed cable
for internal wiring |
7 | 60227 IEC 10 (BVV) (NYM) | Light PVC sheathed cable |
8 | 60227 IEC 42 (RVB) | Flat unsheathed flexible cable |
9 | 60227 IEC 52 (RVV) (H03VV-F、H03VV2-F) | Light PVC sheathed flexible cable |
10 | 60227 IEC 53 (RVV) (H05VV-F、H05VV2-F) | Common PVC sheathed flexible cable |
11 | BV (H07V-U or H07V-R) | Copper conductor PVC insulated cable |
12 | BLV | Aluminum conductor PVC insulated cable |
13 | BVR | Copper conductor PVC insulated flexible cable |
14 | WDZR-BYJ | Copper conductor LSZH insulated cable |
15 | BVV (NYY or NYM) | Copper conductor PVC insulated sheathed
circular cable |
16 | BLVV | Aluminum conductor PVC insulated and sheathed round cable |
17 | BVVB (H05VVH2-F) | Copper conductor PVC insulated and sheathed flat cable |
18 | BLVVB | Aluminum conductor PVC insulated sheathed flat cable |
19 | NMD-90 | Copper conductor PVC/Nylon Insulated PVC Jacked flat cable |
20 | RVS | Twisted copper conductor PVC insulated flexible cable for conection |
21 | AVP | Copper conductor PVC insulated wire with shied for installation |
22 | RVP | Copper conductor PVC insulated flexible cable with shield |
23 | RVVP | Copper conductor PVC insulated, shielded,
PVC sheathed flexible cable |
