YFFB Flat travelling cable is mainly used in power supply, control system, data transmission system and video signal transmission system for variously civil elevators or industrial lifts. Such as urban buildings, railway system, airports, shopping malls, construction sites etc.

Cable Construction

Conductor: Flexible bare copper acc. to IEC 60228, class 5 according to DIN VDE 0295

Insulation: rubber compound (on request)

Core identification: up to 5 core colored, from 6 core black core with white numbers with green/yellow core according to VDE 0293-308

Sheath: Special Rubber compound w (on request)

Characteristics

Conductor Standard: IEC60228 VDE0295

Min. bending radius: 8 x outer diameter

Fixed temperature: –40℃ to 85℃

Moved temperature: –35℃ to 85℃

Normal Voltage: 600V

Test Voltage: 3500V

Advantages:

Flexible, flame retardant, low smoke halogen free, good data transmission, power supply, abrasion resistance, tension resistance,etc
