standard:Q/SMT01-2019
rateds voltages:0.6/1KV
cable long-term allowed working temperature:-60℃ to +200℃
when cable laying temperature:not below 0℃
application:This product is soft,cold resistant,oil resistant to cold and features,is fit for ac rated voltage up to and including 450/750 with cold resistant,oil resistant and other special requirnments of driving,car,transmission machinery and othermobile electric power transmission and cintrol,lighting,communications lines,this product has been widely used in metallurgy,electric power,shipbuilding,ports and other industries.
| Nominal cros section | Conductor structure | Insulation area | Thickness of the sheath | Approximate diameter |
| 3*1.5 | 48/0.2 | 0.6 | 1.4 | 6*13 |
| 4*1.5 | 48/0.2 | 0.6 | 1.4 | 5*15 |
| 5*1.5 | 48/0.2 | 0.6 | 1.5 | 6.5*19 |
| 6*1.5 | 48/0.2 | 0.6 | 1.5 | 6.5*21 |
| 7*1.5 | 45/0.2 | 0.6 | 1.5 | 62*5.8 |
| 8*1.5 | 48/0.2 | 0.6 | 1.5 | 6.7*30 |
| 10*1.5 | 48/0.2 | 0.6 | 1.5 | 6.7*38.5 |
| 12*1.5 | 48/0.2 | 0.6 | 1.5 | 7*47 |
| 13*1.5 | 48/0.2 | 0.6 | 1.5 | 6.2*48.5 |
| 2*2.5 | 79/0.2 | 0.8 | 2.0 | 6.5*10 |
| 3*2.5 | 79/0.2 | 0.8 | 2.0 | 6.5*14 |
| 4*2.5 | 79/0.2 | 0.8 | 2.0 | 6.9*16.5 |
| 5*2.5 | 79/0.2 | 0.8 | 2.0 | 7.2*22.5 |
| 6*2.5 | 79/0.2 | 0.8 | 2.0 | 7.5*27 |
| 7*2.5 | 79/0.2 | 0.8 | 2.0 | 7.5*32.5 |
| 8*2.5 | 79/0.2 | 0.8 | 2.0 | 7.8*34.5 |
| 9*2.5 | 79/0.2 | 0.8 | 2.0 | 7.5*37.5 |
| 10*2.5 | 79/0.2 | 0.8 | 2.0 | 7*42 |
| 12*2.5 | 79/0.2 | 0.8 | 2.0 | 7.5*50.5 |
| 3*4 | 127/0.2 | 1.0 | 2.0 | 8*16 |
| 4*4 | 127/0.2 | 1.0 | 2.0 | 8.5*22 |
| 5*4 | 127/0.2 | 1.0 | 2.0 | 8.5*28 |
| 6*4 | 127/0.2 | 1.0 | 2.0 | 7.5*29 |
| 7*4 | 127/0.2 | 1.0 | 2.0 | 8.5*36 |
| 8*4 | 127/0.2 | 1.0 | 2.0 | 8.5*40 |
| 3*6 | 190/0.2 | 1.0 | 2.0 | 9*19 |
| 4*6 | 190/0.2 | 1.0 | 2.0 | 9.5*24.5 |
| 5*6 | 190/0.2 | 1.0 | 2.0 | 9*30 |
| 6*6 | 190/0.2 | 1.0 | 2.0 | 9*36 |
| 7*6 | 190/0.2 | 1.0 | 2.0 | 9.5*41 |
| 8*6 | 190/0.2 | 1.0 | 2.0 | 944 |
| 10*6 | 190/0.6 | 1.0 | 2.0 | 11.558 |
| 3*10 | 317/0.2 | 1.2 | 2.0 | 10*24 |
| 4*10 | 317/0.2 | 1.2 | 2.2 | 12*33 |
| 6*10 | 317/0.2 | 1.2 | 2.2 | 12*48 |
| 7*10 | 317/0.2 | 1.2 | 2.2 | 11*54 |
| 2*16 | 507/0.2 | 1.2 | 2.5 | 13*21 |
| 3*16 | 507/0.2 | 1.2 | 2.5 | 13*30 |
| 4*16 | 507/0.2 | 1.2 | 2.5 | 13*37 |
| 5*16 | 507/0.2 | 1.2 | 2.5 | 16*45 |
| 6*16 | 507/0.2 | 1.2 | 2.5 | 13*58 |
| 2*25 | 352/0.3 | 1.4 | 3.0 | 16*26 |
| 3*25 | 352/0.3 | 1.4 | 3.0 | 15*35 |
| 4*25 | 352/0.3 | 1.4 | 3.0 | 15*46 |
| 2*35 | 493/0.3 | 1.4 | 3.0 | 18*30 |
| 3*35 | 493/0.3 | 1.4 | 3.0 | 18*42 |
| 4*35 | 493/0.3 | 1.4 | 3.0 | 18*55 |
| 3*50 | 396/0.4 | 1.6 | 3.0 | 20*46 |
| 4*50 | 396/0.4 | 1.6 | 3.0 | 20*55 |
| 3*70 | 555/0.4 | 1.6 | 3.2 | 22*54 |
| 3*95 | 753/0.4 | 1.8 | 3.6 | 29*70 |
| 3*120 | 951/0.4 | 1.8 | 4.0 | 30*72 |
| Type | Name |
| YVFB | Nitrile PVC insulated and sheathed flat flexible cable |
| YVFBP | Nitrile PVC insulated and sheathed wire braided shielding shielding flat flexible cable |
