APPLICATION

This cable can be used for signal transmission between

electronic devices, in computer systems or process control

units.

CHARACTERISTICS

Voltage Rating Uo/U

250/250V

Temperature Rating

Fixed: -30ºC to +80ºC

Flexed: -5ºC to +70ºC

Minimum Bending Radius

Fixed: 5 x overall diameter

Flexed: 7.5 x overall diameter

CONSTRUCTION

Conductor

Class 5 Fine Stranded Bare Copper

Insulation

PVC (Polyvinyl chloride)

Outer Sheath

PVC (Polyvinyl chloride)

Core Identification

Core 1: White

Core 2: Brown

Core 3: Green

Core 4: Yellow

Core 5: Grey

Core 6: Pink

Core 7: Blue

Core 8: Red

Core 9: Black

Core 10: Violet

Core 11: Grey/Pink

Core 12: Red/Blue

Sheath Colour

Grey

STANDARDS

DIN VDE 0812

Flame Retardant according to: IEC 60332-1
